前言
记录总结自己第一次如何使用Flink SQL读写Hudi并同步Hive，以及遇到的问题及解决过程。
版本
Flink 1.14.3Hudi 0.12.0/0.12.1
本文采用Flink yarn-session模式，不会的可以参考之前的文章。
Hudi包
下载地址：https://repo1.maven.org/maven2/org/apache/hudi/hudi-flink1.14-bundle/0.12.1/hudi-flink1.14-bundle-0.12.1.jar
如果想同步Hive的话，就不能使用上面下载的包了，必须使用profileflink-bundle-shade-hive自己打包,这里参考官网：https://hudi.apache.org/cn/docs/syncing_metastore,打包命令
## Hive3
mvn clean package -DskipTests -Drat.skip=true-Pflink-bundle-shade-hive3 -Dflink1.14-Dscala-2.12
## Hive2
mvn clean package -DskipTests -Drat.skip=true-Pflink-bundle-shade-hive2 -Dflink1.14-Dscala-2.12
## Hive1
mvn clean package -DskipTests -Drat.skip=true-Pflink-bundle-shade-hive1 -Dflink1.14-Dscala-2.12
为了避免不必要的麻烦，最好自己修改一下对应的profile中的Hive版本，比如我们环境的Hive版本为HDP的3.1.0.3.1.0.0-78，我们将hive.version对应的值改为3.1.0.3.1.0.0-78再打包就可以了。
方式1、建在内存中、不同步Hive表
这种建表方式，元数据在内存中，退出SQL客户端后，需要重新建表（表数据文件还在）
建表
CREATETABLE test_hudi_flink1 (
id int PRIMARY KEY NOT ENFORCED,
name VARCHAR(10),
price int,
ts int,
dt VARCHAR(10)
)
PARTITIONED BY(dt)
WITH (
'connector'='hudi',
'path'='/tmp/hudi/test_hudi_flink1',
'table.type'='MERGE_ON_READ',
'hoodie.datasource.write.keygenerator.class'='org.apache.hudi.keygen.ComplexAvroKeyGenerator',
'hoodie.datasource.write.recordkey.field'='id',
'hoodie.datasource.write.hive_style_partitioning'='true'
);
PRIMARY KEY和hoodie.datasource.write.recordkey.field作用相同，联合主键时，可以单独放在最后 PRIMARY KEY (id1, id2) NOT ENFORCED
CREATETABLE test_hudi_flink1 (
id1 int,
id2 int,
name VARCHAR(10),
price int,
ts int,
dt VARCHAR(10),
PRIMARY KEY (id1, id2)NOT ENFORCED
)
Insert
insertinto test_hudi_flink1 values(1,'hudi',10,100,'2022-10-31'),(2,'hudi',10,100,'2022-10-31');
至于upadte和delete可以参考官网：https://hudi.apache.org/cn/docs/flink-quick-start-guide
查询
select*from test_hudi_flink1;
通过Flink查询出来的结果是没有Hudi的元数据字段的
方式2、建在Hive Catalog中、不同步Hive表
这种建表方式，会在对应的Hive中创建表，好处是，当我们退出SQL客户端后，再重新启动一个新的SQL客户端，我们可以直接使用Hive Catalog中的表，进行读写数据。
建表
CREATE CATALOG hive_catalog WITH (
'type'='hive',
'default-database'='default',
'hive-conf-dir'='/usr/hdp/3.1.0.0-78/hive/conf'
);
use catalog hive_catalog;
use hudi;
CREATETABLE test_hudi_flink2 (
id int PRIMARY KEY NOT ENFORCED,
name VARCHAR(10),
price int,
ts int,
dt VARCHAR(10)
)
PARTITIONED BY(dt)
WITH (
'connector'='hudi',
'path'='/tmp/hudi/test_hudi_flink2',
'hoodie.datasource.write.keygenerator.class'='org.apache.hudi.keygen.ComplexAvroKeyGenerator',
'hoodie.datasource.write.recordkey.field'='id',
'hoodie.datasource.write.hive_style_partitioning'='true'
);
Insert
insertinto test_hudi_flink2 values(1,'hudi',10,100,'2022-10-31'),(2,'hudi',10,100,'2022-10-31');
查询
select*from test_hudi_flink2;
但是同样地也无法查询Hudi的元数据字段，而且在Hive表中查询此表是会有异常的，因为表结构是这样的：
show createtable test_hudi_flink2;
+----------------------------------------------------+
| createtab_stmt |
+----------------------------------------------------+
|CREATETABLE `test_hudi_flink2`(|
|)|
| ROW FORMAT SERDE |
|'org.apache.hadoop.hive.serde2.lazy.LazySimpleSerDe'|
| STORED AS INPUTFORMAT |
|'org.apache.hadoop.mapred.TextInputFormat'|
| OUTPUTFORMAT |
|'org.apache.hadoop.hive.ql.io.IgnoreKeyTextOutputFormat'|
| LOCATION |
|'hdfs://cluster1/warehouse/tablespace/managed/hive/hudi.db/test_hudi_flink2'|
| TBLPROPERTIES (|
|'flink.connector'='hudi',|
|'flink.hoodie.datasource.write.hive_style_partitioning'='true',|
|'flink.hoodie.datasource.write.recordkey.field'='id',|
|'flink.partition.keys.0.name'='dt',|
|'flink.path'='/tmp/hudi/test_hudi_flink2',|
|'flink.schema.0.data-type'='INT NOT NULL',|
|'flink.schema.0.name'='id',|
|'flink.schema.1.data-type'='VARCHAR(10)',|
|'flink.schema.1.name'='name',|
|'flink.schema.2.data-type'='INT',|
|'flink.schema.2.name'='price',|
|'flink.schema.3.data-type'='INT',|
|'flink.schema.3.name'='ts',|
|'flink.schema.4.data-type'='VARCHAR(10)',|
|'flink.schema.4.name'='dt',|
|'flink.schema.primary-key.columns'='id',|
|'flink.schema.primary-key.name'='PK_3386',|
|'transient_lastDdlTime'='1667129407')|
+----------------------------------------------------+
select*from test_hudi_flink2;
Error: Error while compiling statement: FAILED: SemanticException Line 0:-1 Invalid column reference 'TOK_ALLCOLREF'(state=42000,code=40000)
方式3、建在内存中、同步Hive表
这样建表的好处是，可以利用同步到Hive中的表,通过Hive SQL和Spark SQL查询，也可以利用Spark进行insert、update等，但是Flink SQL客户端退出后，不能利用Hive中的表进行写数据，需要再重新建表
MOR表
建表
配置环境变量HIVE_CONF_DIR
export HIVE_CONF_DIR=/usr/hdp/3.1.0.0-78/hive/conf
CREATETABLE test_hudi_flink3 (
id int PRIMARY KEY NOT ENFORCED,
name VARCHAR(10),
price int,
ts int,
dt VARCHAR(10)
)
PARTITIONED BY(dt)
WITH (
'connector'='hudi',
'path'='/tmp/hudi/test_hudi_flink3',
'table.type'='MERGE_ON_READ',
'hoodie.datasource.write.keygenerator.class'='org.apache.hudi.keygen.ComplexAvroKeyGenerator',
'hoodie.datasource.write.recordkey.field'='id',
'hoodie.datasource.write.hive_style_partitioning'='true',
'hive_sync.enable'='true',
'hive_sync.mode'='hms',
'hive_sync.metastore.uris'='thrift://indata-192-168-44-128.indata.com:9083',
'hive_sync.conf.dir'='/usr/hdp/3.1.0.0-78/hive/conf',
'hive_sync.db'='hudi',
'hive_sync.table'='test_hudi_flink3',
'hive_sync.partition_fields'='dt',
'hive_sync.partition_extractor_class'='org.apache.hudi.hive.HiveStylePartitionValueExtractor'
);
HIVE_CONF_DIR和hive_sync.conf.dir作用是一样的，如果没有配置hive_sync.conf.dir的话就会取HIVE_CONF_DIR，如果都没有配置，同步会有异常，具体看后面的异常解决。
关于同步Hive的参数，官方文档上说hive_sync.metastore.uris是必须的，但是经过验证，不设置也可以，因为hive_sync.conf.dir下面有hive-site.xml读取里面的配置信息获取即可，Spark SQL同步Hive也是读取hive-site.xml的。其他的参数可以自己去了解
同步表
只有在写数据的时候才会触发同步Hive表
insertinto test_hudi_flink3 values(1,'hudi',10,100,'2022-10-31'),(2,'hudi',10,100,'2022-10-31');
然后我们可以看到在Hive库中生成了两张表test_hudi_flink3_ro、test_hudi_flink3_rt,这和我们使用Spark SQL同步的表是一样的，可以用Hive查询，也可以用Spark查询、写数据
MOR表一开始没有生成parquet文件，在Hive里查询为空（RO、RT都为空），我们可以在SparkSQL里再插入几条数据，就可以查询出数据来了
# ro、rt都支持Spark SQL insert
insertinto test_hudi_flink3_ro values(3,'hudi',10,100,'2022-10-31'),(4,'hudi',10,100,'2022-10-31');
insertinto test_hudi_flink3_rt values(5,'hudi',10,100,'2022-10-31'),(6,'hudi',10,100,'2022-10-31');
关于Flink SQL和Spark SQL配置一致性问题：
- hoodie.datasource.write.keygenerator.class 这里设置的为ComplexAvroKeyGenerator，也就是复合主键，原因是Fink SQL 默认值为SimpleKey，但是SparkSQL默认值SqlKeyGenerator，它是ComplexKeyGenerator，也就是默认值为复合主键，但是由于ComplexKeyGenerator在hudi-spark-client中，flink模块没有，所以flink中需要设置hudi-client-common中的ComplexAvroKeyGenerator即可保持一致性（如果keygenerator不一致会导致重复数据）
- hoodie.datasource.write.hive_style_partitioning flink sql默认值为false，但是SparkSQL为true，所以这里设置为true
- hive_sync.partition_extractor_class SparkSQL中默认值为MultiPartKeysValueExtractor，对于本例中的字符串类型的分区字段是支持的，但是Flink SQL中的默认值为SlashEncodedDayPartitionValueExtractor，它要求分区字段必须是日期格式的，所以这里设置为HiveStylePartitionValueExtractor即可解决
- hoodie.allow.operation.metadata.field Flink支持这个配置项，当为true时，Hudi元数据字段中会多一个_hoodie_operation，但是目前Spark还不支持，所以对于这种，对于Flink SQL同步的Hive表，不能再通过Spark SQL写数据，不过后面我会提PR支持
- 我们发现对于Flink的很多配置项key值或者默认值都和Spark或者Hudi Common中不一致，这一点如果需要Flink和Spark配合使用的话，就需要注意保持一致性
COW表
我们来看一下COW表会同步哪些表
建表
CREATETABLE test_hudi_flink4 (
id int PRIMARY KEY NOT ENFORCED,
name VARCHAR(10),
price int,
ts int,
dt VARCHAR(10)
)
PARTITIONED BY(dt)
WITH (
'connector'='hudi',
'path'='/tmp/hudi/test_hudi_flink4',
'table.type'='COPY_ON_WRITE',
'hoodie.datasource.write.keygenerator.class'='org.apache.hudi.keygen.ComplexAvroKeyGenerator',
'hoodie.datasource.write.recordkey.field'='id',
'hoodie.datasource.write.hive_style_partitioning'='true',
'hive_sync.enable'='true',
'hive_sync.mode'='hms',
'hive_sync.metastore.uris'='thrift://indata-192-168-44-128.indata.com:9083',
'hive_sync.conf.dir'='/usr/hdp/3.1.0.0-78/hive/conf',
'hive_sync.db'='hudi',
'hive_sync.table'='test_hudi_flink4',
'hive_sync.partition_fields'='dt',
'hive_sync.partition_extractor_class'='org.apache.hudi.hive.HiveStylePartitionValueExtractor'
);
同步表
写数据触发同步Hive表
insertinto test_hudi_flink4 values(1,'hudi',10,100,'2022-10-31'),(2,'hudi',10,100,'2022-10-31');
因为COW表只有RT表，所以不会通过_rt来区分，同步的表名和配置的表名一致。这点可以参考我之前总结的文章Hudi查询类型/视图总结
+----------------------------------------------------+
| createtab_stmt |
+----------------------------------------------------+
|CREATE EXTERNAL TABLE `test_hudi_flink4`(|
| `_hoodie_commit_time` string COMMENT '',|
| `_hoodie_commit_seqno` string COMMENT '',|
| `_hoodie_record_key` string COMMENT '',|
| `_hoodie_partition_path` string COMMENT '',|
| `_hoodie_file_name` string COMMENT '',|
| `id` int COMMENT '',|
| `name` string COMMENT '',|
| `price` int COMMENT '',|
| `ts` int COMMENT '')|
| PARTITIONED BY(|
| `dt` string COMMENT '')|
| ROW FORMAT SERDE |
|'org.apache.hadoop.hive.ql.io.parquet.serde.ParquetHiveSerDe'|
| WITH SERDEPROPERTIES (|
|'hoodie.query.as.ro.table'='false',|
|'path'='/tmp/hudi/test_hudi_flink4')|
| STORED AS INPUTFORMAT |
|'org.apache.hudi.hadoop.HoodieParquetInputFormat'|
| OUTPUTFORMAT |
|'org.apache.hadoop.hive.ql.io.parquet.MapredParquetOutputFormat'|
| LOCATION |
|'hdfs://cluster1/tmp/hudi/test_hudi_flink4'|
| TBLPROPERTIES (|
|'last_commit_time_sync'='20221030204426056',|
|'spark.sql.sources.provider'='hudi',|
|'spark.sql.sources.schema.numPartCols'='1',|
|'spark.sql.sources.schema.numParts'='1',|
|'spark.sql.sources.schema.part.0'='{"type":"struct","fields":[{"name":"_hoodie_commit_time","type":"string","nullable":true,"metadata":{}},{"name":"_hoodie_commit_seqno","type":"string","nullable":true,"metadata":{}},{"name":"_hoodie_record_key","type":"string","nullable":true,"metadata":{}},{"name":"_hoodie_partition_path","type":"string","nullable":true,"metadata":{}},{"name":"_hoodie_file_name","type":"string","nullable":true,"metadata":{}},{"name":"id","type":"integer","nullable":false,"metadata":{}},{"name":"name","type":"string","nullable":true,"metadata":{}},{"name":"price","type":"integer","nullable":true,"metadata":{}},{"name":"ts","type":"integer","nullable":true,"metadata":{}},{"name":"dt","type":"string","nullable":true,"metadata":{}}]}',|
|'spark.sql.sources.schema.partCol.0'='dt',|
|'transient_lastDdlTime'='1667133869')|
+----------------------------------------------------+
方式4、建在Hive Catalog中、同步Hive表
这样建表的好处是，我们既可以利用Hive Catalog中的表通过Flink SQL写数据，也可以利用同步的Hive表通过Hive SQL查询、Spark SQL读写
MOR表
建表
配置环境变量HIVE_CONF_DIR
export HIVE_CONF_DIR=/usr/hdp/3.1.0.0-78/hive/conf
CREATE CATALOG hive_catalog WITH (
'type'='hive',
'default-database'='default',
'hive-conf-dir'='/usr/hdp/3.1.0.0-78/hive/conf'
);
use catalog hive_catalog;
use hudi;
CREATETABLE test_hudi_flink5 (
id int PRIMARY KEY NOT ENFORCED,
name VARCHAR(10),
price int,
ts int,
dt VARCHAR(10)
)
PARTITIONED BY(dt)
WITH (
'connector'='hudi',
'path'='/tmp/hudi/test_hudi_flink5',
'table.type'='MERGE_ON_READ',
'hoodie.datasource.write.keygenerator.class'='org.apache.hudi.keygen.ComplexAvroKeyGenerator',
'hoodie.datasource.write.recordkey.field'='id',
'hoodie.datasource.write.hive_style_partitioning'='true',
'hive_sync.enable'='true',
'hive_sync.mode'='hms',
'hive_sync.metastore.uris'='thrift://indata-192-168-44-128.indata.com:9083',
'hive_sync.conf.dir'='/usr/hdp/3.1.0.0-78/hive/conf',
'hive_sync.db'='hudi',
'hive_sync.table'='test_hudi_flink5',
'hive_sync.partition_fields'='dt',
'hive_sync.partition_extractor_class'='org.apache.hudi.hive.HiveStylePartitionValueExtractor'
);
同步表
同样写几条数据触发同步Hive
insertinto test_hudi_flink5 values(1,'hudi',10,100,'2022-10-31'),(2,'hudi',10,100,'2022-10-31');
然后我们可以看到在Hive库中生成了三张表test_hudi_flink4、test_hudi_flink4_ro、test_hudi_flink4_rt,其中test_hudi_flink4是Flink格式的，和上面的方式2中的表结构一样，不能用Hive查询，但是可以在Flink中写数据、查询数据，对于test_hudi_flink4_ro、test_hudi_flink4_rt，我们就可以用Hive查询，也可以用Spark查询、写数据。
COW表
但是对于COW表来说因为同步的表名没有_rt也就是和Hive Catalog表名一样，这样就有问题，所以我们需要区分出Hive Catalog表和同步的表名，一种方式是修改hive_sync.table，另一种方式是Hive Catalog表和同步表保存在不同的Hive Database中，比如下面的示例
CREATE CATALOG hive_catalog WITH (
'type'='hive',
'default-database'='default',
'hive-conf-dir'='/usr/hdp/3.1.0.0-78/hive/conf'
);
use catalog hive_catalog;
use flink_hudi;
CREATETABLE test_hudi_flink6 (
id int PRIMARY KEY NOT ENFORCED,
name VARCHAR(10),
price int,
ts int,
dt VARCHAR(10)
)
PARTITIONED BY(dt)
WITH (
'connector'='hudi',
'path'='/tmp/hudi/test_hudi_flink6',
'table.type'='MERGE_ON_READ',
'hoodie.datasource.write.keygenerator.class'='org.apache.hudi.keygen.ComplexAvroKeyGenerator',
'hoodie.datasource.write.recordkey.field'='id',
'hoodie.datasource.write.hive_style_partitioning'='true',
'hive_sync.enable'='true',
'hive_sync.mode'='hms',
'hive_sync.metastore.uris'='thrift://indata-192-168-44-128.indata.com:9083',
'hive_sync.conf.dir'='/usr/hdp/3.1.0.0-78/hive/conf',
'hive_sync.db'='hudi',
'hive_sync.table'='test_hudi_flink6',
'hive_sync.partition_fields'='dt',
'hive_sync.partition_extractor_class'='org.apache.hudi.hive.HiveStylePartitionValueExtractor'
);
这样Catalog表保存在flink_hudi库中，同步的表保存在hudi库中
insertinto test_hudi_flink6 values(1,'hudi',10,100,'2022-10-31'),(2,'hudi',10,100,'2022-10-31');
异常解决
记录异常信息及解决方法，由于没有及时整理，顺序可能有点乱
不同步Hive
最开始使用的在maven里下载的包，在Hive里查询发现没有同步表，后来在官网https://hudi.apache.org/cn/docs/syncing_metastore，发现要使用profileflink-bundle-shade-hive自己打包
mvn clean package -DskipTests -Drat.skip=true-Pflink-bundle-shade-hive3 -Dflink1.14-Dscala-2.12
但是用自己的打的包依旧不成功，在Flink SQL客户端没有异常，就很费解，后来发现在Flink yarn-session对应的web界面的Job Manager菜单里能看到具体的日志信息，比如写Hudi的Starting Javalin，这样就好办了，根据具体的异常信息对应解决即可。
异常1
2022-10-2916:02:41,694 WARN hive.metastore[]- set_ugi()not successful, Likely cause: new client talking to old server. Continuing without it.
org.apache.thrift.transport.TTransportException:null
at org.apache.thrift.transport.TIOStreamTransport.read(TIOStreamTransport.java:132)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
解决方法：配置环境变量HIVE_CONF_DIR或者配置参数hive_sync.conf.dir，这个问题困扰了我一整天，因为关于这个配置网上没有资料，我是在源码中找到的答案：
public static org.apache.hadoop.conf.Configuration getHiveConf(Configuration conf){
String explicitDir = conf.getString(FlinkOptions.HIVE_SYNC_CONF_DIR, System.getenv("HIVE_CONF_DIR"));
org.apache.hadoop.conf.Configuration hadoopConf = new org.apache.hadoop.conf.Configuration();
if (explicitDir !=null){
hadoopConf.addResource(new Path(explicitDir,"hive-site.xml"));
}
return hadoopConf;
}
// StreamWriteOperatorCoordinator
this.hiveConf= new SerializableConfiguration(HadoopConfigurations.getHiveConf(conf));
异常2
java.lang.NoSuchMethodError: org.apache.parquet.schema.Types$PrimitiveBuilder.as(Lorg/apache/parquet/schema/LogicalTypeAnnotation;)Lorg/apache/parquet/schema/Types$Builder;
at org.apache.parquet.avro.AvroSchemaConverter.convertField(AvroSchemaConverter.java:177)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.parquet.avro.AvroSchemaConverter.convertUnion(AvroSchemaConverter.java:242)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.parquet.avro.AvroSchemaConverter.convertField(AvroSchemaConverter.java:199)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.parquet.avro.AvroSchemaConverter.convertField(AvroSchemaConverter.java:152)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.parquet.avro.AvroSchemaConverter.convertField(AvroSchemaConverter.java:260)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.parquet.avro.AvroSchemaConverter.convertFields(AvroSchemaConverter.java:146)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.parquet.avro.AvroSchemaConverter.convert(AvroSchemaConverter.java:137)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.common.table.TableSchemaResolver.readSchemaFromLogFile(TableSchemaResolver.java:485)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.common.table.TableSchemaResolver.readSchemaFromLogFile(TableSchemaResolver.java:468)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.common.table.TableSchemaResolver.fetchSchemaFromFiles(TableSchemaResolver.java:604)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.common.table.TableSchemaResolver.getTableParquetSchemaFromDataFile(TableSchemaResolver.java:251)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.common.table.TableSchemaResolver.getTableAvroSchemaFromDataFile(TableSchemaResolver.java:117)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.common.table.TableSchemaResolver.hasOperationField(TableSchemaResolver.java:537)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.util.Lazy.get(Lazy.java:53)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.common.table.TableSchemaResolver.getTableSchemaFromLatestCommitMetadata(TableSchemaResolver.java:208)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.common.table.TableSchemaResolver.getTableAvroSchemaInternal(TableSchemaResolver.java:176)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.common.table.TableSchemaResolver.getTableAvroSchema(TableSchemaResolver.java:138)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.common.table.TableSchemaResolver.getTableParquetSchema(TableSchemaResolver.java:156)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.sync.common.HoodieSyncClient.getStorageSchema(HoodieSyncClient.java:103)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.hive.HiveSyncTool.syncHoodieTable(HiveSyncTool.java:206)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.hive.HiveSyncTool.doSync(HiveSyncTool.java:157)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.hive.HiveSyncTool.syncHoodieTable(HiveSyncTool.java:141)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.sink.StreamWriteOperatorCoordinator.doSyncHive(StreamWriteOperatorCoordinator.java:335)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.sink.StreamWriteOperatorCoordinator.syncHive(StreamWriteOperatorCoordinator.java:326)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.sink.StreamWriteOperatorCoordinator.handleEndInputEvent(StreamWriteOperatorCoordinator.java:426)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.sink.StreamWriteOperatorCoordinator.lambda$handleEventFromOperator$3(StreamWriteOperatorCoordinator.java:278)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at org.apache.hudi.sink.utils.NonThrownExecutor.lambda$wrapAction$0(NonThrownExecutor.java:130)~[hudi-flink1.14-bundle-0.12.0.jar:0.12.0]
at java.util.concurrent.Executors$RunnableAdapter.call(Executors.java:511)[?:1.8.0_181]
at java.util.concurrent.FutureTask.run(FutureTask.java:266)[?:1.8.0_181]
at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1149)[?:1.8.0_181]
at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:624)[?:1.8.0_181]
at java.lang.Thread.run(Thread.java:748)[?:1.8.0_181]
原因是jar包冲突，根据异常信息可知hudi包的org.apache.parquet.schema.Types这个类可能和flink环境下面的其他jar包冲突，经排查，发现hive-exec.*jar里也有一样的类名，将该jar包删除，验证问题解决。（在之前的文章中有写到因为缺某些类，才会将hive-exec.*jar放到flink下面，现在验证不缺这个类了，如果还有的话，可以找其他没有冲突的包替代）
异常3
Caused by: org.apache.flink.util.FlinkRuntimeException: Failed to start the operator coordinators
at org.apache.flink.runtime.scheduler.DefaultOperatorCoordinatorHandler.startAllOperatorCoordinators(DefaultOperatorCoordinatorHandler.java:90)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.scheduler.SchedulerBase.startScheduling(SchedulerBase.java:585)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.jobmaster.JobMaster.startScheduling(JobMaster.java:965)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.jobmaster.JobMaster.startJobExecution(JobMaster.java:882)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.jobmaster.JobMaster.onStart(JobMaster.java:389)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.rpc.RpcEndpoint.internalCallOnStart(RpcEndpoint.java:181)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.rpc.akka.AkkaRpcActor$StoppedState.lambda$start$0(AkkaRpcActor.java:624)~[flink-rpc-akka_0f8ea990-3e27-4639-9ea1-d92b6879facc.jar:1.14.3]
at org.apache.flink.runtime.concurrent.akka.ClassLoadingUtils.runWithContextClassLoader(ClassLoadingUtils.java:68)~[flink-rpc-akka_0f8ea990-3e27-4639-9ea1-d92b6879facc.jar:1.14.3]
at org.apache.flink.runtime.rpc.akka.AkkaRpcActor$StoppedState.start(AkkaRpcActor.java:623)~[flink-rpc-akka_0f8ea990-3e27-4639-9ea1-d92b6879facc.jar:1.14.3]
... 20 more
Caused by: java.lang.NoClassDefFoundError: org/apache/hadoop/hive/conf/HiveConf
at org.apache.hudi.sink.StreamWriteOperatorCoordinator.initHiveSync(StreamWriteOperatorCoordinator.java:315)~[hudi-flink1.14-bundle-0.12.1.jar:0.12.1]
at org.apache.hudi.sink.StreamWriteOperatorCoordinator.start(StreamWriteOperatorCoordinator.java:191)~[hudi-flink1.14-bundle-0.12.1.jar:0.12.1]
at org.apache.flink.runtime.operators.coordination.OperatorCoordinatorHolder.start(OperatorCoordinatorHolder.java:194)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.scheduler.DefaultOperatorCoordinatorHandler.startAllOperatorCoordinators(DefaultOperatorCoordinatorHandler.java:85)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.scheduler.SchedulerBase.startScheduling(SchedulerBase.java:585)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.jobmaster.JobMaster.startScheduling(JobMaster.java:965)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.jobmaster.JobMaster.startJobExecution(JobMaster.java:882)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.jobmaster.JobMaster.onStart(JobMaster.java:389)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.rpc.RpcEndpoint.internalCallOnStart(RpcEndpoint.java:181)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.rpc.akka.AkkaRpcActor$StoppedState.lambda$start$0(AkkaRpcActor.java:624)~[flink-rpc-akka_0f8ea990-3e27-4639-9ea1-d92b6879facc.jar:1.14.3]
at org.apache.flink.runtime.concurrent.akka.ClassLoadingUtils.runWithContextClassLoader(ClassLoadingUtils.java:68)~[flink-rpc-akka_0f8ea990-3e27-4639-9ea1-d92b6879facc.jar:1.14.3]
at org.apache.flink.runtime.rpc.akka.AkkaRpcActor$StoppedState.start(AkkaRpcActor.java:623)~[flink-rpc-akka_0f8ea990-3e27-4639-9ea1-d92b6879facc.jar:1.14.3]
... 20 more
Caused by: java.lang.ClassNotFoundException: org.apache.hadoop.hive.conf.HiveConf
at java.net.URLClassLoader.findClass(URLClassLoader.java:381)~[?:1.8.0_181]
at java.lang.ClassLoader.loadClass(ClassLoader.java:424)~[?:1.8.0_181]
at sun.misc.Launcher$AppClassLoader.loadClass(Launcher.java:349)~[?:1.8.0_181]
at java.lang.ClassLoader.loadClass(ClassLoader.java:357)~[?:1.8.0_181]
at org.apache.hudi.sink.StreamWriteOperatorCoordinator.initHiveSync(StreamWriteOperatorCoordinator.java:315)~[hudi-flink1.14-bundle-0.12.1.jar:0.12.1]
at org.apache.hudi.sink.StreamWriteOperatorCoordinator.start(StreamWriteOperatorCoordinator.java:191)~[hudi-flink1.14-bundle-0.12.1.jar:0.12.1]
at org.apache.flink.runtime.operators.coordination.OperatorCoordinatorHolder.start(OperatorCoordinatorHolder.java:194)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.scheduler.DefaultOperatorCoordinatorHandler.startAllOperatorCoordinators(DefaultOperatorCoordinatorHandler.java:85)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.scheduler.SchedulerBase.startScheduling(SchedulerBase.java:585)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.jobmaster.JobMaster.startScheduling(JobMaster.java:965)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.jobmaster.JobMaster.startJobExecution(JobMaster.java:882)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.jobmaster.JobMaster.onStart(JobMaster.java:389)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.rpc.RpcEndpoint.internalCallOnStart(RpcEndpoint.java:181)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.rpc.akka.AkkaRpcActor$StoppedState.lambda$start$0(AkkaRpcActor.java:624)~[flink-rpc-akka_0f8ea990-3e27-4639-9ea1-d92b6879facc.jar:1.14.3]
at org.apache.flink.runtime.concurrent.akka.ClassLoadingUtils.runWithContextClassLoader(ClassLoadingUtils.java:68)~[flink-rpc-akka_0f8ea990-3e27-4639-9ea1-d92b6879facc.jar:1.14.3]
at org.apache.flink.runtime.rpc.akka.AkkaRpcActor$StoppedState.start(AkkaRpcActor.java:623)~[flink-rpc-akka_0f8ea990-3e27-4639-9ea1-d92b6879facc.jar:1.14.3]
这个异常就是使用在maven下载的包同步hive产生的异常，但是无法在Flink yarn-session对应的web界面看日志，因为yarn-session对应的任务会跑挂掉，我们可以通过下面的命令查看日志信息
yarn logs -applicationId application_1666247158647_0121异常4
Caused by: org.apache.flink.streaming.runtime.tasks.StreamTaskException: Could not instantiate outputs inorder.
at org.apache.flink.streaming.api.graph.StreamConfig.getOutEdgesInOrder(StreamConfig.java:488)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.streaming.runtime.tasks.StreamTask.createRecordWriters(StreamTask.java:1612)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.streaming.runtime.tasks.StreamTask.createRecordWriterDelegate(StreamTask.java:1596)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.streaming.runtime.tasks.StreamTask.<init>(StreamTask.java:376)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.streaming.runtime.tasks.StreamTask.<init>(StreamTask.java:359)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.streaming.runtime.tasks.StreamTask.<init>(StreamTask.java:332)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.streaming.runtime.tasks.StreamTask.<init>(StreamTask.java:324)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.streaming.runtime.tasks.StreamTask.<init>(StreamTask.java:314)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.streaming.runtime.tasks.OneInputStreamTask.<init>(OneInputStreamTask.java:75)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at sun.reflect.NativeConstructorAccessorImpl.newInstance0(Native Method)~[?:1.8.0_181]
at sun.reflect.NativeConstructorAccessorImpl.newInstance(NativeConstructorAccessorImpl.java:62)~[?:1.8.0_181]
at sun.reflect.DelegatingConstructorAccessorImpl.newInstance(DelegatingConstructorAccessorImpl.java:45)~[?:1.8.0_181]
at java.lang.reflect.Constructor.newInstance(Constructor.java:423)~[?:1.8.0_181]
at org.apache.flink.runtime.taskmanager.Task.loadAndInstantiateInvokable(Task.java:1582)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.taskmanager.Task.doRun(Task.java:740)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at org.apache.flink.runtime.taskmanager.Task.run(Task.java:575)~[flink-dist_2.12-1.14.3.jar:1.14.3]
at java.lang.Thread.run(Thread.java:748)~[?:1.8.0_181]
Caused by: java.io.IOException: unexpected exception type
这个原因是因为yarn-session所用的hudi包和sql-client所用的hudi包版本不一致，改为一致即可
其他异常
比如缺相关依赖包异常，去环境上Hive路径下拷贝对应的jar包到Flink路径下即可
总结
本文记录了自己使用Flink SQL读写Hudi表并同步Hive的一些配置，并且做了Flink SQL和Spark SQL的一致性配置。其实关于Flink SQL读写Hudi还有一个HoodieHiveCatalog也可以使用，有时间等我研究明白了，再分享给大家。
文章来源网络，作者：管理，如若转载，请注明出处：https://shuyeidc.com/wp/247192.html<
